Axiomtek tBOX400-510-FL High-Performance Transportation Embedded System

Axiomtek has released the tBOX400-510-FL, a two-in-one transportation-certified box PC with built-in layer two managed PoE switch for IP surveillance applications.

The tBOX400-510-FL is certified with CE (Class A) and FCC and is in compliance with E-Mark, ISO 7637-2, EN 50155, EN 50121-3-2 and EN 45545-2, IEC 60945 and DNV 2.4. This high-performance transportation box PC is powered by the seventh generation Intel® Core™ (Kaby Lake) or Intel® Celeron® 3965U processors, along with dual DDR4 SO-DIMM slots for up to 32GB of memory. The built-in ten-port managed switch is powered by Qualcomm’s chip. With its high-performance, industrial-grade design and full-strict certifications, the tBOX400-510-FL is suited for transportation-related applications such as on-board video surveillance and video management.

Axiomtek’s tBOX400-510-FL has a built-in ten-port managed switch with eight-port 10/100 Mbps PoE and two-port Gigabit LANs, featuring VLAN, QoS and PoE scheduling for the more secure and smooth network.

For reliable operation in severe environments, the rugged fanless transportation box computer is designed to withstand a wide temperature range from -40°C to 60°C and vibration of up to 3Grms. It also supports a wide voltage input range: 9V to 36V DC for vehicle applications, 14V to 32V DC for marine applications, and 24V to 110V DC for railway applications.

The all-in-one tBOX400-510-FL has two M12 A-coded Gigabit LANs and eight M12-type D-coded PoE ports with a total power budget of 120W in the rear panel, four USB 3.0 ports, two audio ports, one Gigabit LAN with Intel® i210-IT, one DVI-I, and one RS-232/422/485 are in front of the system. An isolated DIO is reserved and available upon request.

Besides, this IP30-rated embedded system supports two swappable 2.5in SATA HDD drives with Intel® RAID 0/1 function. There are three full-size PCI Express Mini Card and two SIM card slots for 3G / 4G, GPS, Wi-Fi and Bluetooth connections. The DC power input is available in M12 connector for railway applications or terminal block for marine and vehicle applications. One PoE power input is available for external PoE power supply.

For more product information or pricing, fill out the enquiry form on this page.
