Palm-sized Fanless Embedded System Certified with E-Mark and ISO 7637 for Vehicle Applications

The tBOX100-838-FL comes with the onboard quad-core Intel® Atom™ processor E3845, along with onboard DDR3L memory up to 4GB.

The rugged tBOX100-838-FL is certified with E-Mark and ISO 7637 for vehicle applications. It features five BNC connectors with four video-in and one audio-in as well as one capture card for DVR surveillance applications. For system integrators with extensive storage needs, the box PC offers one 2.5in SATA HDD and one mSATA.

In addition, the tBOX100-838-FL comes with one PCI Express Mini Card slot and one SIM card slot for 3G/4G, GPS, Wi-Fi and Bluetooth applications. It was designed to withstand a wide temperature range from -40°C to +70°C and vibration up to 3 Grms. It is equipped with intelligent power management at wide voltage range 9-36VDC.

The tBOX100-838-FL is also compliant with EN 50155, EN 50121, DNV 2.4, and IEC 60945 for use in rolling stock and marine industries.

Qseven Module with Intel® Apollo Lake Processor

The Q7M311 – Axiomtek’s new Qseven module in a small form of 70 x 70 mm – has adopted the 14nm Intel® Pentium® N4200 and Celeron® N3350 processors. The Q7M311 supports 4GB (or optionally up to 8GB) DDR3L memory onboard and 32GB eMMC flash memory. It was built to withstand a wide operating temperature range from -20°C to +70°C. Both the CPU and the DDR3L RAM are soldered to deliver reliable and excellent computing performance. Dual-display is supported with resolution up to 4K through two DDI ports. Read More

Fanless, Feature-rich 3.5in Embedded Boards

The CAPA312 is powered by the Intel® Pentium® processor N4200 or Celeron® processor N3350. It was designed for operational stability in a wide operating temperature range from -20°C to +60°C (or optionally up to +70°C) and requires only +12V DC power input. It features one SATA-600 socket and one mSATA interface for storage needs.

It also comes with rich I/O connectors, various display interfaces and two PCI Express Mini Card slots for a wide array of industrial applications. To ensure reliable operation, the CAPA312 supports TPM 1.2, watchdog timer, hardware monitoring features.

15.6in Fanless Touch Panel PC with Ultra Slim Design

The GOT5153W-845 is powered by the Intel® Celeron® processor N3060. Carrying an ultra slim design with a light weight, the user-friendly human machine interface adopts a 15.6in WXGA TFT widescreen LCD display with LED backlight and 300 nits brightness.

To maximum flexibility, the GOT5153W-845 offers projected capacitive touch or 5-wire flat resistive touch, providing two types of power input: 9-36V DC power with a terminal block connector and an AC power adapter with a screw type connector. Five membrane keys on its front bezel also offer an easier way to adjust LCD on / off, brightness and volume.
