Steve Cockerell, marketing director for road and rail at Bentley Systems, talks about the scale of the endeavour, the software involved in building a ’digital railway’ and how such a complex project has influenced the development of Bentley’s modelling software.

Crossrail is Europe’s largest construction project, and with total funding of £14.8bn, it stands as one of the biggest single infrastructure investments ever undertaken in the UK.

Running over 100km from Reading and Heathrow in the west, to Shenfield and Abbey Wood in the east, the new service is expected to bring an additional 1.5 million people within 45 minutes’ commuting distance of London’s key business districts.

Since the project’s very beginning, software company Bentley Systems has been heavily involved in the planning, design and construction process.

Here, Steve Cockerell looks back on the working partnership and joint evolution, explaining how some of Bentley’s most advanced software has helped build the railway of the future.

Eva Grey: Could you describe the ongoing partnership between Bentley and Crossrail?

Steve Cockerell: Crossrail is one of – if not the – biggest construction projects in Europe at the moment and it’s been designed in a virtual environment, in 3D, 4D and 5D, adding the time and cost element to it using software from Bentley.
