The Howard Street Tunnel (HST) expansion project will facilitate the movement of double-stacked container freight trains to and from the Port of Baltimore. Credit:
The construction of the HST expansion project is expected to start in the first quarter (Q1) of 2022. Credit:
The expansion project is expected to be completed in 2025. Credit:

The Howard Street Tunnel is a 2.73km-long freight rail tunnel that runs under Baltimore city in Maryland, US. CSX Transportation, a freight railroad operator in the US and Canada, owns and operates the tunnel.

The Howard Street Tunnel project (HST project) includes the expansion of the vertical clearance of the 126-year-old tunnel, as well as at multiple locations along the I-95 rail corridor between Baltimore and Philadelphia, to accommodate double-stack intermodal containers.

Double stacking, which involves the stacking and transportation of two shipping containers on top of each other on a train, will provide more cost-effective transportation of freight by rail, when compared to highway trucks.

Estimated to cost $466m, the HST project is expected to generate more than 13,000 jobs, including 6,550 construction jobs and 7,300 permanent positions.

The official ground-breaking event for the project was held in November 2021. Construction is expected to commence in the first quarter (Q1) of 2022 and to be completed in 2025.

Howard Street Tunnel expansion details

The existing vertical clearances of the tunnel and certain locations along the corridor fall short of the 21ft required for double-stack transportation by up to 18 inches.

As part of the HST project, the tunnel will be reconstructed to increase the clearance by 18 inches and superstructure work will be performed on three additional bridges in Baltimore. The North Avenue bridge will be partially replaced, while the Guilford Avenue and Harford Road bridges will be completely replaced.

Improvements to the railroad infrastructure at other areas in Maryland, Delaware, and Pennsylvania will include the lowering of the track below the structures.

The HST project marks the final phase of CSX’s modernisation programme designed to make its entire intermodal network capable of providing double-stack train service.

Key players involved

The expansion is being jointly implemented by CSX Transportation, Maryland Port Administration (MPA), and the Federal Railroad Administration (FRA).

CSX is managing and designing the expansion, including executing the preliminary engineering, final design, and construction works.

Funding for the Howard Street Tunnel expansion project

The project is being funded by the US Department of Transportation (USDOT) through its Infrastructure for Rebuilding American (INFRA) grant programme, CSX, the Maryland Department of Transportation (MDOT), and the Pennsylvania Department of Transportation.

The INFRA programme aims to provide financial assistance to significant highway and freight projects.

The Maryland Port Administration was awarded INFRA grant funding, worth $125m, in July 2019 to support the design and construction of the project.

The remaining project costs will be met through $113m from CSX, $202.5m from the state government, $22.5m from Pennsylvania, and $3m from federal highway formula funds.

Project benefits

Removing vertical clearance restrictions and undertaking other upgrades on the I-95 corridor will help improve freight transportation and boost containerised freight train capacity along the corridor.

It will enhance intermodal connectivity between the markets on the east coast and the Midwest US, reduce congestion along the I-95 corridor, and cut emissions.

Contractors involved

RK&K, a planning, engineering, environmental, and construction management/inspection services company, was engaged to perform cultural resources studies, including historic architecture, archaeology, impact assessment, and development of mitigation measures.

The contract also covered environmental assessment, as well as air, noise, natural resources, and socioeconomic evaluations.
